Master Shredder
Added · Updated
♥ 11 likes
Well, I got this frame from Pete at 2ndStroke a couple of years ago for my birthday, I wanted strippers but this was cool enough.
I collected the parts for the build over a span of about 8 months, chopped the frame(stretched and sleeved), rebuilt all the components, found a PP derbi, etc.
-disengagement/pedal gear removal
-heavily modified cases
-modified Puch Gilardoni cylinder
-modfied metrakit 70cc head
-1977 piston port crank
-TJT variator, standard rear contra
-24mm intake made by me
-mikuni tm24, 155 main, big ole k&n filter, standard reeds
-modified Honda cr80r exhaust, 30mm header, slip fit and sprung by me
-modified clutch, loco springs at 5k haha
-HPI mini rotor ignition at 2.4mm btdc
-20x28 gearing
Here's a quick video...
https://www.facebook.com/photo.php?v=10102398760981242&set=vb.68109636&type=2&theater
Big thanks to Jesus Christ my Lord and Savior, Dan Kastner, Thom, Papi, Beezy, Sam McKay, and DERBI RABASA
Parts
engine
- Derbi Piston Port
- Derbi Piston Port 77
- Peugeot 70cc Gilardoni
exhaust
- Hacked Cr80r
electrical
carburetion
Tuning
Main 155 · Idle 12.5
Heman Run — 12 years, 3 months ago
Hi. Really cool build. How does it perform off-road?
